Large Bottom Loading Furnace

Large Bottom Loading Furnace

Our Services:
Furnace Consultation, Indonesia | Furnace Installation, Indonesia | Furnace Spart Parts, Indonesia

Coverage Area:
Jakarta, Tangerang, Bogor, Bekasi, Bandung, Surabaya, Cikarang, Depok, Semarang, Yogyakarta, Medan, Makassar, Palembang, Samarinda, Palangkaraya, Pontianak, Denpasar, Padang, Manado, Palu, Bandar Lampung, Tarakan, Kendari, Malang, Balikpapan, Indonesia

Product Description

Main Features
  • Manual Elevator or Electric lift bell type.
  • Integrated Structure with elegant design.
  • Vacuum forming ceramic fiber chamber or solid refractory brick as chamber materials
  • Heaters: HRE resistance wire/SIC Rod / Mosi2 rod with different operating temperatures.
  • Microprocessor Digital PID controller or any brand controller is available.
  • Exhaust chimney valve is available for gas emission.
  • Bottom floor available for all sides loading.
  • CE compliant.
Computer Remote Control system is available
1200°C Bell Furnace
1200°C OEM Three Zones Split Tube Furnace
1400°C Bell Furnace
1200°C OEM Three Zones Split Tube Furnace
1700°C Bell Furnace


Technical Parameters
Model Volume (L) Chamber Size Operate Temp (°C) Voltage (V) Max Temp (°C) Heating Element
WTS-96-12A 96L 400x600x400 1100°C 380 V 1200°C HRE
WTS-288-12A 288L 600x800x600 1100°C 380 V 1200°C HRE
WTS-640-12A 640L 800x1000x800 1100°C 380 V 1200°C HRE
WTS-1200-12A 1200L 1000x1200x1000 1100°C 380 V 1200°C HRE
WTS-96-14A 96L 400x600x400 1300°C 380 V 1400°C SIC Rod
WTS-288-14A 288L 600x800x600 1300°C 380 V 1400°C SIC Rod
WTS-640-14A 640L 800x1000x800 1300°C 380 V 1400°C SIC Rod
WTS-1200-14A 1200L 1000x1200x1000 1300°C 380 V 1400°C SIC Rod
WTS-96-17A 96L 400x600x400 1600°C 380 V 1700°C Mosi2 Rod
WTS-288-17A 288L 600x800x600 1600°C 380 V 1700°C Mosi2 Rod
WTS-288-17A 288L 800x1000x800 1600°C 380 V 1700°C Mosi2 Rod
